HZ028QPBS18-A0
240*320
50.00*69.20*2.35
43.20*57.60
43.20*57.60
ST7789
The full name of TFT is Thin Film Transistor. Each pixel on a TFT display screen is driven by a thin film transistor, and a TFT display screen is an active matrix liquid crystal display device. A semi reflective and semi transmissive TFT screen can display images using the light source provided by the built-in backlight, or by utilizing external light without the need for backlight.
Description | 2.8 inch TFT LCD display |
Outline size | 50.00*69.20*2.35mm |
Active area | 43.20*57.60mm |
Resolution | 240*320 |
Controller | ST7789 |
Interface | SPI |
Driving Voltage | 2.8V |
backlight | LED*4,white |
Operating temperature | -20~70 ℃ |
Storage temperature | -30~80 ℃ |
The full name of TFT is Thin Film Transistor. Each pixel on a TFT display screen is driven by a thin film transistor, and a TFT display screen is an active matrix liquid crystal display device. A semi reflective and semi transmissive TFT screen can display images using the light source provided by the built-in backlight, or by utilizing external light without the need for backlight.
Description | 2.8 inch TFT LCD display |
Outline size | 50.00*69.20*2.35mm |
Active area | 43.20*57.60mm |
Resolution | 240*320 |
Controller | ST7789 |
Interface | SPI |
Driving Voltage | 2.8V |
backlight | LED*4,white |
Operating temperature | -20~70 ℃ |
Storage temperature | -30~80 ℃ |
